Description:
ZL2 Mechanical Seal
Replacement to:
John Crane 2 type seal
Aesseal P0204U seal
Flowserve 52 seal
US Seal D seal

Operational Conditions:
Temperature: -20℃ to +120℃
Pressure: ≤1.4MPa
Speed: ≤15m/s
Seat Type:
Standard: T11
Alternative: T20, CT20

Materials:
Stationary Ring: Ceramic (Alumina), Silicon Carbide Reaction Bonded, Silicon Carbide Sintered Pressureless, Ni-binder Tungsten Carbide, Co-binder Tungsten Carbide
Rotary Ring: Resin Impregnated Carbon Graphite (Furan), Antimony Impreg, Carbon Graphite, Silicon Carbide Sintered Pressureless, Silicon Carbide Reaction Bonded, Co-binder Tungsten Carbide, Ni-binder Tungsten Carbide
Secondary Seal: Nitrile (NBR), Ethylene Propylene (EPDM), Fluorocarbon Rubber (Viton)

Applications:
Clean water,
Sewage water
Oil and other moderately corrosive fluids
