Description:

ZL20, 20T Mechanical Seal

Replacement to:
Burgmann MG920/ D1-G50 seal
John Crane type 2 seal
Flowserve 200 seal
Latty T200 seal
Roten RB02 seal
Roten 21 seal
Sealol 43 CE short seal
Sterling 212 seal

Operational Conditions:
Temperature: -20℃ to +120℃
Pressure: ≤1.0MPa
Speed: ≤15m/s
Seat Type:
Standard: CT20
Alternative: CT24, G60

Materials:
Stationary Ring: Ceramic (Alumina), Silicon Carbide Reaction Bonded, Silicon Carbide Sintered Pressureless, Ni-binder Tungsten Carbide, Co-binder Tungsten Carbide
Rotary Ring: Resin Impregnated Carbon Graphite (Furan), Antimony Impreg, Carbon Graphite, Silicon Carbide Sintered Pressureless, Silicon Carbide Reaction Bonded, Co-binder Tungsten Carbide, Ni-binder Tungsten Carbide
Secondary Seal: Nitrile (NBR), Ethylene Propylene (EPDM), Fluorocarbon Rubber (Viton)

Applications:
Clean water,
Sewage water
Oil and other moderately corrosive fluids
